Product Summary
The MC68HC811E2CFN2 is an 8-bit microcontroller unit. It combines the M68HC11 central processor unit (CPU) with high-performance, on-chip peripherals.
Parametrics
Absolute maximum ratings: (1)Supply voltage VDD:–0.3V to +7.0V; (2)Input voltage VIn:–0.3V to +7.0V; (3)Current drain per pin excluding VDD, VSS, AVDD, VRH, VRL, and XIRQ/VPPE:25mA; (4)Storage temperature:–55℃ to +150℃.
Features
Features: (1)Synchronous serial peripheral interface (SPI) ; (2)8-channel, 8-bit analog-to-digital (A/D) converter ; (3)Asynchronous non-return-to-zero (NRZ) serial communications interface (SCI) ; (4)8-bit pulse accumulator ; (5)Real-time interrupt circuit ; (6)Computer operating properly (COP) watchdog system ; (7)38 general-purpose input/output (I/O) pins; (8)Power-saving stop and wait modes ; (9)Low-voltage devices available (3.0–5.5 Vdc).
